000885 The 4-4-0 inside cylinder locomotive included a number of features that were to appear on later Great Eastern locomotive classes, including a circular polished steel smokebox door surround (instead of the usual horizontal straps) and decorative splashers.[2] Class pioneer No 1900 Claud Hamilton featuring red lining and connecting rods, copper chimney cap and GER coat of arms was much admired when it was exhibited at the 1900 Paris Exposition.[4]

2a874d save -electro

000885 The 4-4-0 inside cylinder locomotive included a number of features that were to appear on later Great Eastern locomotive classes, including a circular polished steel smokebox door surround (instead of the usual horizontal straps) and decorative splashers.[2] Class pioneer No 1900 Claud Hamilton featuring red lining and connecting rods, copper chimney cap and GER coat of arms was much admired when it was exhibited at the 1900 Paris Exposition.[4]

000885 Although credited to James Holden, the Locomotive Superintendent of the Great Eastern, Frederick Vernon Russell (Holden's Chief Designer) is thought to have contributed substantially to the design of the Claud Hamiltons; while researching his Some Classic Locomotives of 1949, C.H. Ellis was informed by Russell that during the process of designing the locomotive "Mr Holden, by then a valetudinarian was making a long recuperative stay in Egypt."[3]

000885 The Claud Hamilton, particularly in its original GER blue livery, is widely considered one of the most elegant locomotive designs of the pre-grouping era.[1] In his 1955 history of the Great Eastern Railway, Cecil J. Allen devotes a whole chapter to the class and noted that Of all the locomotive designs that emerged from Stratford Works during the reign of James Holden, the one destined to achieve the greatest fame, beyond question, was his Claud Hamilton type 4-4-0, of which the pioneer example, No. 1900 Claud Hamilton, took the rails in 1900.

000885 During the Edwardian era, they were the flagship express locomotive on the Great Eastern Main Line, and although displaced on the heaviest express trains by the larger S69 class from 1911 (itself a 4-6-0 development of the Claud design), members of the class were used on passenger and goods services throughout the Eastern Region until 1960. No locomotives of the three classes survived to preservation

000885 The GER Classes S46, D56 and H88 (classified Classes D14, D15, and D16 by the London and North Eastern Railway) were three classes of similar 4-4-0 steam locomotive designed by James Holden (S46 and D56) and A. J. Hill (H88) for the Great Eastern Railway. They were given the nickname Claud Hamilton after the pioneer engine of the class, named after Lord Claud Hamilton (1843–1925) the chairman of the Great Eastern Railway. The D56 class of 1903-4 evolved the design to include a square-topped Belpaire firebox. The H88 class of 1923 featured a larger superheated boiler, leading them to be known as Super Clauds. Many earlier members of the class were rebuilt during their working life.

000885 Nope, we have to learn about the "Claud Hamiltons" then we will be done.

000885 In the 1942 LNER renumbering scheme, the class was allocated the range 7415–7494, but only eleven (7426/37/49/67/70/72/76/79/82/88/91) were renumbered before the scheme was abandoned due to the war. In the 1946 scheme, the class was allocated the 1500–1580 block, with gaps for the two withdrawn locomotives.

8a598a ...Are we done?

000885 As the Scottish locomotives also required new boilers, a new design was started in 1941, based on the old design but with a round-topped firebox and other detail changes. Thirty of these Diagram 25A boilers were manufactured at Doncaster and Stratford between 1942 and 1946. Nine were sent to Inverurie Works for fitting to B12 locomotives, the remainder went to Stratford for fitting to class J20 locomotives. The B12 locomotives fitted with the Diagram 25A boiler (1500/04/05/07/08/11/24/26) were classified as class B12/4.

000885 Starting in 1932, a programme began of rebuilding the B12 locomotives with larger diameter boilers. The Diagram 99A boilers utilised were 5-foot-6-inch (1,676 mm) diameter, compared with the 5-foot-1 1⁄8-inch (1,553 mm) diameter originals. These rebuilt locomotives were classified as class B12/3, and as they had a higher axleload, none of the Scottish-allocated locomotives were included. The last to be rebuilt was 8549 in 1944, leaving 8534 as the last English B12/1; but it was withdrawn the following year without being rebuilt.

000885 As newer power became available, the locomotives’ low axleload made them ideal candidates for transfers elsewhere. consequently, between 1931 and 1942, twenty-five locomotives were transferred to Scotland for use on the former Great North of Scotland Railway lines.

258281 Two pickup trucks making love, American made, built Ford Tough, Two beautiful murder machines, American angels in the sky, Grown men cry. -Ez

000885 All the B12 locomotives were fitted with vacuum ejectors between 1924 and 1929 (the 1928 batch had them from new). Fifty-five locomotives were fitted with ACFI feedwater heaters between 1927 and 1934, but these were removed between 1934 and 1942. The first substantive change was the fitting of Lenz poppet valves to the 1928 batch (from new), and six of the ex-GE locomotives (8516/19/25/32/33/40).[5] These locomotives were then classified as class B12/2. The poppet valves were not a great success and they all reverted to or were converted to piston valve engines between 1931 and 1934.

000885 Seventy were still in service at the 1923 grouping, the LNER adding 7000 to the numbers of nearly all the ex-Great Eastern locomotives, including the Class S69 locomotives. A further ten were ordered in 1928 to ease a power shortage caused by the stalled development on a new class of 4-6-0 locomotives, and the cancellation of the planned suburban 2-6-4T tank locomotive due to the adverse press publicity caused by the Sevenoaks derailment.[4]

000885 At the time of their introduction, the "Claud Hamilton" 4-4-0s were becoming outclassed on the heaviest express. Although an enlarged 4-4-0 design was mooted,[3] it was realised that any such design would have too high an axle load for the tracks of the Great Eastern Railway, which had a relatively low restriction. Another design constraint was the short turntables used at the time. This meant that a 4-6-0 design was decided upon, although the design was relatively short compared to similar designs introduced at the same time.

000885 Seventy-one S69 locomotives were built between 1911 and 1921 and numbered 1500–1570. Fifty-one of these were built at the GER's Stratford Works and the remaining 20 by William Beardmore and Company. A further 10 locomotives were built by Beyer, Peacock and Company for the LNER in 1928 and numbered 8571–8580.[2] From 1948 the British Railways numbers were 61500–61580 (with gaps).

bee6c4 idk

000885 The Great Eastern Railway (GER) Class S69, also known as 1500 Class, and later classified B12 by the London and North Eastern Railway (LNER) is a class of 4-6-0 steam locomotive designed to haul express passenger trains from London Liverpool Street station along the Great Eastern Main Line.[1] Originally they were designed by S. D. Holden, but were much rebuilt, resulting in several subclasses.

258281 Two trucks having sex, Two trucks having sex, My muscles, my muscles, Involuntarily flex, Two trucks having sex, Two trucks having sex, My muscles, my muscles, Involuntarily flex. -Ez

000885 Number 564/7564/65462 is preserved on the North Norfolk Railway and owned by the Midland and Great Northern Joint Railway Society.[17] In 2002 the locomotive reached the end of a major overhaul and was painted in LNER (numbered 7564) and BR black numbered 65462) liveries for the duration of its boiler ticket. It originally operated in these liveries when classified as a J15 in LNER and BR days. Following withdrawal from service in 2013, the locomotive received another overhaul (completed 2015) where it was outshopped in GER lined blue and sporting its original number of 564 and representing its days when classified as a Y14.

000885 As built all the locomotives had a stovepipe chimney; this was replaced in LNER days by a cast chimney with a small lip. The original Worsdell and early Holden series had three-ring boilers with the steam dome placed in the middle. Also the Worsdell boilers had a flat grate, however from 1890 Holden developed a boiler with a sloping grate and a two-ring telescopic barrel with the dome located well forward. The advantage of the dome position was a short 5½ inch steam pipe which limited pressure drop between the boiler and the cylinders. This boiler was adopted as standard and persisted on all Great Eastern Locomotives down to 1898; from then on it was perpetuated on the smaller locomotives as long as these remained essentially in their original configuration - which could be down to the 1960s.[2]

000885 On 10–11 December 1891, the Great Eastern Railway's Stratford Works built one of these locomotives and had it in steam with a coat of grey primer in 9 hours 47 minutes; this remains a world record. The locomotive then went off to run 36,000 miles (58,000 km) on Peterborough to London coal trains before coming back to the works for the final coat of paint. It lasted 40 years and ran a total of 1,127,750 miles (1,814,940 km).[3]

000885 All twenty passed to the LNER in 1923. Thirteen class J69 locomotives were lent to the War Department in October 1939,[2] of which five had been built as Class S56. They were sold to the War Department in October 1940,[3] where they were used on the Melbourne and Longmoor Military Railways.[2] The remaining locomotives were renumbered 8617–8636 in order of construction; however gaps were left where the locomotives sold to the War Department would have been. At nationalisation in 1948, the remainder passed to British Railways, who added 60000 to their number. Post-war withdrawals started in 1958, and by 1962 all had been retired.[4]
